FBE coating for pipeline products

FBE is the abbreviation of “Fusion Bonded Epoxy“. There are two types of FBE coating: single layer and double layer. FBE coating generally refers to a single-layer fusion-bonded epoxy coating.

The single-layer FBE coating uses a special fusion-bonded epoxy powder coating as the film-forming material. This epoxy powder coating is a thermosetting coating, which is processed by mixing and crushing solid epoxy resin, curing agent and various auxiliaries. The steel pipe is shot blasted and preheated at intermediate frequency before painting, and then the epoxy powder coating is sprayed on the surface of the heated steel pipe by electrostatic spraying method, and it is melt-bonded on the surface of the steel pipe and cured to form a coating. The FBE coating is generally a one-time film-forming structure with a film thickness of 300~500μm.

FBE coating for pipeline product

FBE coating has the advantages of strong adhesion to steel, good film integrity, resistance to cathodic disbondment, soil stress resistance and abrasion resistance, but the ability to resist mechanical damage and moisture and heat resistance is poor. FBE coating can be used for external anticorrosion of steel buried pipelines or underwater pipeline facilities with a working temperature of -30~100 degrees Celsius.

FBE coating for pipeline product

The advantages of FBE coating are as mentioned above, and it is also one of our more commonly used coatings, which can effectively protect steel. Hebei Haihao Group specializes in producing engineering pipelines, and is very professional in anti-corrosion operations of pipelines, including FBE anti-corrosion of pipelines, which has been widely received by customers for many years. Welcome new and old customers to come to consult and order!
