ASTM A106 Gr B seamless steel pipes

ASTM A106 Gr B seamless steel pipes are one of the most common material of seamless steel pipes.ASTM A106  Gr B is the material,of which ASTM A106 is the standard and Gr B is the grade(also known as brand number).

ASTM A106 Gr B seamless steel pipes

ASTM A106 Gr B seamless steel pipes

Application of ASTM A106 Gr B seamless steel pipes:

ASTM A106 seamless  steel pipe (also known as ASME SA106 Pipe) is commonly used in the construction of oil and gas refineries,power plants,petrochemical plants, boilers, and ships where the piping must transport fluids and gasses that exhibit higher temperatures and pressure levels.

Chemical Composition ASTM A106 carbon steel seamless pipes:

Chemical Composition Grade A Grade B Grade C
Carbon max. % 0.25 0.30 0.35
Manganese % 0.27 to 0.93 0.29 to 1.06 0.29 to 1.06
Phosphorous, max. % 0.035 0.035 0.035
Sulfur, max. % 0.035 0.035 0.035
Silicon, min.% 0.10 0.10 0.10
Chrome, max. % 0.40 0.40 0.40
Copper, max. % 0.40 0.40 0.40
Molybdenum, max. % 0.15 0.15 0.15
Nickel, max. % 0.40 0.40 0.40
Vanadium, min.% 0.08 0.08 0.08

Notes:

  • Total of Cr, Cu, Mo, Ni, and V shall not exceed 1%;
  • If the carbon content is lower than the stipulated maximum carbon content, the content of manganese in A106 seamless steel tube can be increased by 0.06% above the stipulated maximum manganese content for every 0.01% reduction of carbon content, but the maximum content shall not exceed 1.35%.
ASTM A106 Gr B seamless steel pipes

ASTM A106 Gr B seamless steel pipes

Haihao Group is a world leader in the supply of ASTM A106/ ASME SA 106 seamless steel pipe and stocks a full range of grades B/C in a size rage of NPS 1/8″ to NPS 48″, with nominal wall thickness as given in ANSI B36.10.A full range of ASTM A106 Gr B stock is available in Schedules 10 through 160, STD, XS, XXS.Unscheduled wall thicknesses available up to 4 inches.

We also can supply other types steel pipes,such as ERW/SAW steel pipe,galvanized steel pipe,oil casing pipe,etc.The specification of steel pipe as follows:

Sizes (Seamless): 1/2″ NB – 30″ NB
Sizes (ERW): 1/2″ NB – 24″ NB
Sizes (SAW): 16″ NB – 100″ NB

Wall Thickness available:
Schedule 20 – Schedule XXS (heavier on request) up to 250 mm thk.

Material Grades:

High Temperature Seamless Pipe ASTM A106 Gr. B/C,API 5L Gr. B, ASTM A53 Gr. B
Heat Exchanger Seamless Tube ASTM A179
Low Temperature Seamless Pipe ASTM A333 Gr. 3/6
Low Temperature Seamless Tube ASTM A334 Gr. 6
High Yield Seamless Pipe API 5L Gr. X42/X46/X52/X56/X60/X65/X70/X80 PSL-1/PSL-2
High Yield Seamless Pipe ISO 3183 Gr.L245, L290, L320, L360, L390, L415, L450, L485
Atmospheric & Low Temp EFW Pipes ASTM A671 Gr. CC60/CC65/CC70
High Pressure & Moderate Temp EFW Pipes ASTM A672 Gr. B60/B65/B70/C55/C60/C65/C70
High Yield ERW/SAW Pipe API 5L Gr. X42/X46/X52/X56/X60/X65/X70/X80 PSL-1/PSL-2
High Yield ERW/SAW Pipe ISO 3183 Gr.L245, L290, L320, L360, L390, L415, L450, L485

If you want to know more about steel pipes(seamless steel pipes,galvanized steel pipes,welded steel pipes,ERW/SAW steel pipes,etc),butt welding pipe fittings(45°/90°/180° elbow,tee,reducer,cap,bend,etc),forged pipe fittings,forged flanges(weld neck flange,slip on flange,blind flange,lap joint flange,flat flange,etc),you can feel free to contact us:sales@haihaogroup.com
