Socket Weld Tee-Straight Tee,Reducing Tee,Lateral Tee

Socket weld tee is a kind of high pressure three-way pipe connection fitting,it has a branch from the main run of the pipe that can change fluid direction.Like the other fittings,it has a trapezoidal area where the pipe can inserted into the tee branch and weld together.It is formed by round forged steel or ingot processed by lathe and it commonly used in small diameter systems.Socket weld tee has T-shaped or Y-shaped,commonly divided into equal tee and reducing tee.We can supply & manufacture equal tee,reducing tee,straight tee,Y tee.

ANSI ASME B16.11 socket weld equal tee

ANSI ASME B16.11 socket weld equal tee

Socket weld equal tee: Three branches of socket weld tee have same diameters.

Socket weld reducing tee: The branch diameter is smaller than main diameter.

Socket weld straight tee: A straight tee means a tee of pipe fitting which the branch outlet has a 90 degree direction turning from the main pipe of the tee.It can be equal tee or reducing tee.

Socket weld lateral tee

Socket weld lateral tee

Socket weld lateral tee:  The lateral tee divide two branch pipes:one is same direction with the inflow pipe,the other have a 45 degree angle to inflow pipe.

Socket weld Y-shaped tee: The Y-shaped tee has two branch pipes at a 45 degree angle,and the two branch pipes are symmetrical to the centerline of the inflow pipe which means the two outflow direction are both at 22.5 degree to the inflow direction.

Specifications of the socket weld tee:

Size: 1/8″-4″

Pressure: 3000#,6000#,9000#

Thickness: SCH 10,SCH 40,SCH 80,SCH 160

Standards: ANSI/ASME B16.11,

Materials:

Carbon steel: ASTM A105,A350 LF2,etc

Stainless steel: ASTM A182 F304,F304L,F316,F316L,F321,F347,F310,F44,F51,etc.

Alloy steel: ASTM A182 F1,F5,F9,F11,F22,F91,ASTM A694 F42,F46,F52,F56,F60,F65,F70,etc.

Coating: black,yellow paint,varnish,anti-rust oil,galvanized,epoxy coating or as for clients’ requirements.

Package: In wooded cases or pallets,or as for clients’ requirements.

Applications: Steel tee is widely used in pipe networks for convey liquids and gases.

Socket weld pipe tees normally used in high pressure pipeline systems in different industries as below:

  • Oil and Gas,petrochemicals.
  • Medical science.
  • Power stations of electric or nuclear.
  • Environment control.
  • Aerospace constructions.
  • Fire protection systems.
  • Mining slurry.
  • Shipbuilding.

Haihao Group manufacture all types socket weld pipe tees according to international standards or customers’ requirements.We also supply other types forged pipe fittings like elbows,caps,bends,coupling,reducer,nipple,outlet,etc.If you want to know more about our pipeline products,please email us:sales@haihaogroup.com
