Threaded Pipe Elbows

Threaded pipe elbow(also known as screw pipe elbow) is a pipe fitting that changes the direction of the pipeline in the pipeline system,and the.It is mainly used for small pipe diameter.According to the angle,it can be divided into 45 degree threaded elbow and 90 degree threaded elbow,according to the engineering needs also include 60 degree threaded elbow and other degree threaded elbows.Haihao Group could produce 45 degree threaded elbow and 90 degree threaded elbow from the size DN6 (1/8″) to DN100 (4″).Usually the order specification is DN15 (1/2″) ~ DN100 (4″).If beyond the specifications,and we can process as customer’s drawings.

Stainless steel forged threaded elbow A182 F316 90 degree

Specifications of threaded pipe elbows:

Haihao Group manufacture threaded pipe elbows in different standards such as ANSI/ASME B16.11,BS 3799,EN 10226-1,EN 10226-2,etc.

The materials of threaded elbow are carbon steel,stainless steel and alloy steel,as follows:

Carbon Steel: ASTM A105,A350 LF2,etc.

Stainless Steel: ASTM A182 F304,F304L,F316,F316L,F321,F347,F310,F44,F51,etc.

Alloy Steel: ASTM A182 F1,F5,F9,F11,F22,F91,ASTM A694 F42,F46,F52,F56,F60,F65,F70,etc.

The pressure rating is 2000LB,3000LB,6000LB.

And matching the pipe thickness grades are SCH80,SCH160,XXS accordingly.

Coating: black,yellow paint,varnish,anti-rust oil,galvanized,epoxy coating or as for clients’ requirements.

Package: In wooded cases or pallets,or as for clients’ requirements.

Applications:Petroleum,chemical,machinery,boiler,electric power,shipbuilding,construction,etc.

Haihao Group manufacture forged pipe fittings and butt welding pipe fittings,which contain elbow,tee,reducer,cap,nipple,bend,coupling,outlet,etc.If you want to know more about our pipe fittings,please email us:sales@haihaogroup.com
